| Device |
| Image Sensor |
1/2.9" CMOS image sensor
|
| Max. Resolution |
2592 x 1944 (5MP) |
| Lens |
f2.8mm / F1.6 |
| Viewing Angle |
106.8° (Horizontal) / 68.8° (Vertical) / 134.2° (Diagonal) |
| Min Illumination |
0.01 Lux / F1.6, 0 Lux (IR LED ON) |
| Shutter Speed |
AES |
| IR LED |
3 units |
| IR Effective Distance |
Up to 30 meters |
| Day / Night |
YES |
| WDR Mode |
DWDR |
| RTC (real-time clock) |
NTP / Manual |
| Video |
| Compression |
H.265 / H.264 / MJPEG |
| Video Resolution |
2592 x 1944 / 2560 x 1440 / 2048 x 1536 / 1080P / 720P / D1 / VGA / 640 x 360 / CIF |
| Frame Rate |
25 IPS @ 2592 x 1922, 2560 x 1440 & 2048 x 1536
30 IPS @ 1920 x 1080, 1280 x 720, 640 x 480 & 320 x 240 |
| Video Profile |
High profile / Main profile / Baseline |
| Multiple Video Streaming |
2 streams |
| S/N Ratio |
More than 52dB (AGC off) |
| Bitrate Control |
CBR / VBR |
| Image Mode |
Normal / Super Starlight / Forced Frame Rate |
| Image Enhancement |
DWDR / BLC / HLC / 2D DNR / 3D DNR |
| Day / Night Switch |
Auto / Schedule / Manual |
| Forced Anti-flicker |
YES |
| Defog |
YES |
| White Balance |
AWB |
| Image Orientation |
Flip / Mirror |
| Privacy Mask |
4 customized areas |
| Text Overlay |
YES |
| OSD Title |
Location / font size / text configurable; English & Chinese characters supported |
| Audio |
| Line in |
YES |
| Line out |
YES
|
| Encoding |
G711 / G711A / AAC |
| Audio Adjustment |
Input & Output |
| Event |
| Detection Mode |
Human (Day & Night) / Motion |
| Detection Schedule |
YES |
| Motion Detection Area |
1x1, 2x2, 3x3, 3x4, 4x4, 8x8, 16x16, 22x18 |
| Human Detection Alert |
Audio alert with customized mp3 audio file(s) |
| Storage |
| Overwrite |
YES |
| Maximum Recoding Time / per File |
2, 5, 10, 20 & 30 minutes configurable |
| Recording Schedule |
YES |
| Network |
| LAN Port |
RJ45 connector x 1 |
| LAN Speed |
10/100 Based-T Ethernet |
| Supported Protocols |
TCP/IP, ICMP, HTTP, DHCP, DNS, RTP, RTSP, NTP, IPv4, IPv6, HTML5, ONVIF |
| ONVIF Compatible |
YES (Profile S) |
| Number of Online Users |
6 |
| Security |
Up to 10 user accounts with different access levels and passwords
IP address filtering
Digest authentication |
| Remote Access |
Internet Explorer 6 and above |
| General |
| Operating Temperature |
-30℃ ~ 50℃ |
| Operating Humidity |
30% ~ 90% |
| POE |
YES (IEEE 802.3af) |
| Power Source (±10%) |
PoE (IEEE 802.3af) / DC12V |
| Power Consumption (±10%) |
PoE: 6W; DC adapter: 5W |
| Certification |
CE / FCC |
| Casing |
IP67 |
